Electromagnet Lock
7F-1, No.240, Sec.2, Da-Tung Rd, Sijhih Dist. (221), New Taipei City, Taiwan

Tel: +886-2-8691-9370       Fax: +886-2-8691-9310       E-mail: marketing@auviss.com
ASL-150:
-Magnetic lock for sliding door.
-Power supply DC12V or AC110V/220V.
-Holding fore: 80KG/175LBS
-Build-in photo couplers input contact and adapter.
-Adjustable width (59mm~89mm) for use of different sliding doors' slots.
-Input of DC12V to the reader when AC current is used with maximum of 200mA
overload protection.
-All-in-one design for easy installation. The lock itself would not have any
residual    magnetism.
-The lock itself is equipped with release switch and indicator for better
maintenance of the sliding doors.
-Built-in photo coupler connects with egress delay circuit push button point for
easy installation.
ASL-180/R:
-Compact size magnetic lock, widely adaptation.
-Power supply: DC12V.
-Holding Force: 150KG/300LBS.
-Fail-safe type (Power to lock).
-ASL180: W/O monitor output.
-ASL180R: Built-in monitor output.
ASL-200/S/T/D:
-Magnetic door lock.
-Power supply: DC 12V or DC 24V (Optional).
-Holding Force: 250KG/600LBS.
-Fail-safe type (Power to lock).
-Options: Lock status sensor, timer and door.
-Low power consumption, high efficiency.
-ASL-200: Built-in indicator & monitor output.
-ASL-200S: W/O indicator & monitor output.
-ASL-200T: Built-in time delay, indicator & monitor output.
-ASL-200D: Double lock, built-in indicator & monitor output
-Magnetic door lock.
-Power supply: DC 12V or DC 24V (Optional).
-Holding Force: 500KG/1200LBS.
-Fail-safe type (Power to lock).
-Options: Lock status sensor, timer and door.
-Low power consumption, high efficiency.
-ASL-220: Built-in indicator & monitor output.
-ASL-220S: W/O indicator & monitor output.
-ASL-220T: Built-in time delay, indicator & monitor output.
-ASL-220D: Double lock, built-in indicator & monitor output
ABR-180/200/220 L & Z bracket:
-Suitable for in-swing door.
-ABR-180: To used with ASL-180 magnetic lock.
-ABR-200: To used with ASL-200 magnetic lock.
-ABR-220: To used with ASL-220 magnetic lock.
AEB-200/220
-Especially for the use of ASL-200/220 armature.
-Suitable for 90º out-swing door.
-Sturdy built for durability.
-Simple and easy installation, with screw
position     adjustable function.
AEB-200/220 U bracket:
-To be used with AEB-200/220 armature plate
housing.
-Suitable for glass (thickness of 9mm-12mm).
-Stainless steel built for durability.
-Rubber plate and steel plate for strong holding
-Power supply: DC 12V or DC 24V (Optional).
-Holding Force: AGL200-500KG/1200LBS.
AGL220-250KG/600LBS
-Fail-safe type (Power to lock).
-Stainless Steel Case.
-Threaded conduit fitting.
-Built-in lock status sensor
-Suitable for outdoors.
